;; Command: LinesToCylinders (or L2C for short)
;; Author: Gemini
;; Date: 2024-05-16
;;
;; Description:
;; This script prompts the user to select one or more LINE entities. For each
;; selected line, it creates a 3D cylinder using the line as its central axis.
;; The radius of the created cylinders is fixed at 5 units.
;;
;; How to Use:
;; 1. Load this file into AutoCAD using the APPLOAD command.
;; 2. Type "LINES2CYL" or "L2C" in the command line and press Enter.
;; 3. Select the lines you want to convert into cylinders.
;; 4. Press Enter to confirm your selection. The cylinders will be created.
;; -----------------------------------------------------------------------------
(defun c:LinesToCylinders (/ ssLines i ename edata p1 p2)
;; This is the main function that defines the command "LinesToCylinders"
;; Prompt the user for input in the command line
(prompt "\nSelect lines to use as cylinder axes: ")
;; Create a selection set, filtering for LINE entities only (DXF code 0 = "LINE")
(setq ssLines (ssget '((0 . "LINE"))))
;; Check if the selection set is not nil (i.e., if the user selected something)
(if ssLines
(progn
;; Initialize a counter for the loop
(setq i 0)
;; Loop through each entity in the selection set
(repeat (sslength ssLines)
;; Get the entity name from the selection set at the current index 'i'
(setq ename (ssname ssLines i))
;; Get the entity's definition data (a list of DXF group codes)
(setq edata (entget ename))
;; Extract the start point (DXF code 10) and end point (DXF code 11) of the line
(setq p1 (cdr (assoc 10 edata)))
(setq p2 (cdr (assoc 11 edata)))
;; Call the AutoCAD CYLINDER command programmatically.
;; The dot "." ensures the standard command is used.
;; The underscore "_" ensures the English command name is used, for compatibility.
;;
;; Command sequence breakdown:
;; "._CYLINDER" : Starts the command.
;; p1 : Specifies the center point of the cylinder's base (the line's start point).
;; 5 : Sets the radius to 5.
;; "_A" : Chooses the "Axis Endpoint" option.
;; p2 : Specifies the other end of the axis (the line's end point).
(command "._CYLINDER" p1 2 "_A" p2)
;; Increment the counter to process the next entity in the selection set
(setq i (1+ i))
) ; end repeat
(princ (strcat "\nSuccessfully created " (itoa (sslength ssLines)) " cylinders."))
) ; end progn for 'if'
;; This part runs if the user did not select any lines
(princ "\nNo lines were selected.")
) ; end if
;; Exit the LISP routine cleanly, suppressing the return value in the command line
(princ)
)
;; Define a shorter alias for the command for easier access.
;; Now you can type either "LinesToCylinders" or "L2C".
(defun c:L2C () (c:LinesToCylinders))
(princ "\nLISP file loaded. Type LINES2CYL or L2C to run.")
(princ)
Conversation
with Gemini
in autocad vlisp code. user select a bunch of lines. the code uses the
lines as axle to create cylinders radius 5
Show thinking
Of course. I'll create a VLISP file that you can load into AutoCAD. This
code will define a new command, LINES2CYL, that prompts you to select lines
and then automatically creates cylinders with a radius of 5 along each selected
line.
Here is the VLISP code file.
Lines to
Cylinders
8 Sept, 17:36
Try again without
Canvas
I've created the LISP file for you. To use it, simply load lines_to_cylinders.lsp into your
AutoCAD session using the APPLOAD command. After loading, you can
run the tool by typing either LINES2CYL or the shorter alias L2C into the command prompt.
